Mitsubishi Triton Pajero 4M41 Injector Issue Quick Diagnosis

Mitsubishi Triton Pajero 4M41 Injector Issue Quick Diagnosis

The Mitsubishi 4M41 engine powers many Mitsubishi Pajero and Triton models. Its solid build and durability, the 4M41 is also found in light and medium-duty vehicles, as it's related to the 4M50 engine. Even with its tough nature, this engine has vulnerabilities—one common issue concerns the fuel injectors.

Australian driving, especially with exposure to impure diesel (containing water or rust), can affect your Mitsubishi fuel injectors. If experiencing performance issues, poor fuel, or concerns about emissions, injector diagnostics may be required.

This blog offers a concise yet comprehensive guide to diagnosing frequent injector issues in Mitsubishi Triton and Pajero 4M41 engines, including warning signs to look out for and their potential indications, as well as when and where to replace the injector.

Why Injector Issues Are Common in 4M41 Engines

The 4M41 is built to last, but its injectors are sensitive to fuel quality. In Australia, fuel contamination—particularly water and sediment—is more common than many realise. Over time, this contamination leads to wear, corrosion, and inefficient spray patterns, ultimately affecting performance and reliability.

Modern common-rail diesel injectors operate under extreme pressure and precision. When even a small disruption occurs, such as poor fuel atomisation or combustion seal leaks, it can manifest as serious driveability issues.

Common Signs of Injector Problems in Mitsubishi Triton and Pajero

Below are some of the common issues:

1. Black Smoke from the Exhaust

Excessive black smoke from the exhaust is a clear indicator of a worn or clogged injector failing to atomise fuel properly. In such cases, replacing the faulty injector is the most effective solution. If blow-by is present due to worn copper washers, the injector must be removed, recut if necessary, and replaced along with new seals to restore proper combustion and prevent further engine damage.

2. Engine Knock or Ticking Sound

An engine knock or ticking sound, especially during cold starts, is often caused by injectors delivering fuel at incorrect timings. Rather than risking long-term damage from uneven combustion pressure, it's best to replace the faulty injector identified through diagnostic testing. Injector replacement resolves irregular fuelling patterns and eliminates abnormal engine noise linked to injector wear.

3. Rough Idling or Misfire

Rough idling or misfires typically result from injectors supplying too much or too little fuel to one or more cylinders. When testing confirms an injector fault, immediate replacement is recommended to restore stable combustion. Delaying replacement can lead to more serious engine problems, making injector replacement a practical and necessary fix.

4. Poor Fuel Economy

 A noticeable drop in fuel efficiency often points to leaky or inefficient injectors that over-deliver or poorly atomise fuel. Replacing injectors that fail flow rate or leak-back tests is essential to correcting fuel-air ratio imbalances and preventing the ECU from overcompensating. Injector replacement quickly restores optimal fuel economy and engine efficiency.

5. Unpleasant Exhaust Smell

 A strong smell of unburnt fuel from the exhaust usually indicates a malfunctioning or leaking injector. In such cases, replacing the affected injector and fitting a new sealing washer is the most effective solution. This prevents further combustion issues, eliminates exhaust odours, and ensures the engine runs cleanly and efficiently.

6. Injector Overheating Due to Tuning Modifications

Performance tuning to increase boost and engine power is a common practice among enthusiasts, but it often comes at a cost, especially if stock injectors are pushed beyond their intended capacity. When injectors are overworked, they operate at significantly higher temperatures, which can lead to nozzle overheating. This results in issues such as jamming, poor atomisation, black smoke, excessive engine rattle, or, in some cases, a complete failure to start.

If these symptoms arise after tuning, it's essential to inspect the injectors. The most reliable solution is to replace the affected injectors and detune the vehicle to prevent further damage. Alternatively, upgrading to high-flow injectors such as +30% performance injectors can safely support increased fuel demands. Pairing this upgrade with proper dyno tuning ensures the correct air-fuel mixture, optimal combustion, and sustained engine reliability under enhanced performance conditions.

Quick Diagnostic Tips for 4M41 Injector Problems

Below are a few tips that can be followed:

Scan Tool: Use an OBD-II scanner to pull the injector correction values. A value that is far from zero usually indicates an issue.

Injector Leak-Back Test: A leak-back test measures how much fuel is flowing through the injector return line. An inordinate amount of back leak indicates an internal failure.

Cylinder Cutout Test: Identify which cylinder isn't performing at full output.

Exhaust Smoke Types:

  • Black smoke = bad combustion
  • White smoke = unburnt fuel
  • Blue smoke = oil burning (less likely to be injector related)

If any of these tests point to a fault, replacing the faulty injector is often the most effective and long-term solution.

When to Replace Injectors?

Injectors don't last forever, and while Mitsubishi do not define a replacement interval,
Most injector issues occur between 150,000 km and 200,000 km for Mitsubishi Triton injectors and Mitsubishi Pajero injectors.

If you're experiencing any of the signs described above, it could be worth having a Mitsubishi injector service performed on your vehicle or replacing the injector.

Take Away

The longevity of your engine, fuel efficiency, and overall performance will ultimately rely on keeping your fuel injectors in the best condition possible. Typically, these common symptoms are connected to injector problems (black smoke, engine knock, misfiring, bad fuel economy).

If testing, servicing or replacing is required, TL Ranger Diesel provides reliable and affordable options. Here are some of the reasons TL Ranger Diesel is Australia's trusted diesel injector replacement choice:

  • Affordable injector replacements - Quality diesel injectors at competitive prices.
  • Half Price exchange program - Send your old injectors back to receive an instant 50% off your replacements.
  • Fast delivery Australia-wide - Same day dispatch to reduce downtime of your vehicle.
  • Injector Testing & Servicing - Accurate and lowest cost services that are generally less than those of competitors.
  • Reliable performance injectors - Possible diesel injector replacements include Mitsubishi Triton, Pajero Sport, Outlander, Toyota Hilux, Land Cruiser, Prado, Nissan Navara, and many more popular diesel vehicles.

Whether experiencing symptoms of injector failure or simply wanting to safeguard against injector failure, buying diesel injectors from a specialist like TL Ranger Diesel assures you of reliable injector performance, reasonable price and good value for money.
